The UI-5220RE PoE is fitted with the ON Semiconductor monochrome or color WVGA sensor (MT9V032STM/MT9V032STC). The global shutter enables you to capture fast-moving objects. Thanks to the optional HDR (high dynamic range) mode, the CMOS sensor delivers excellent images even in high dynamic, high contrast scenes. The 1/3" sensor format makes the camera the ideal replacement for standard analog video cameras at no great expense.

The PoE version also provides two additional general purpose I/Os (GPIOs). The power supply is provided by the screw-on, dust proof and splash water proof M12 circular connector.

Data

The UI-5240RE PoE is a particularly powerful industrial camera with the e2v 1.3 megapixel CMOS sensor. This is one of the most sensitive sensors in the IDS product portfolio and it is available in monochrome, color (EV76C560ABT/EV76C560ACT), and NIR versions (EV76C661ABT). Besides its outstanding sensitivity to light in CCD quality, the camera also has a range of other distinctive features: For example, the sensor provides two global shutter and two rolling shutter modes, which you can switch between while the camera is in operation. This makes the sensor extremely flexible if requirements or ambient conditions change. There are also up to four areas of interest (AOI). You can use these either to check several features simultaneously or to capture AOIs in a sequence of exposures using a wide range of different parameters.

The PoE version also provides two additional general purpose I/Os (GPIOs). The power supply is provided by the screw-on, dust proof and splash water proof M12 circular connector.

Data

The UI-5250RE PoE with the e2v CMOS sensor with 2 megapixel resolution is an especially high-performance and versatile industrial camera (EV76C570). It has one of the most sensitive sensors in the IDS product portfolio and it is available in monochrome and color versions. Besides its outstanding sensitivity to light in CCD quality, the camera also has a range of other distinctive features: The sensor allows you to switch between various shutter modes, which allow you to capture sharp images of moving objects or extremely low-noise, high-contrast images. There are also up to four areas of interest (AOI). You can use these either to check several features simultaneously or to capture AOIs in a sequence of exposures using a wide range of different parameters.

The PoE version also provides two additional general purpose I/Os (GPIOs). The power supply is provided by the screw-on, dust proof and splash water proof M12 circular connector.

Data

The UI-5460RE PoE is fitted with the extremely light-sensitive 3.1 megapixel CMOS sensor (MT9T001) from ON Semiconductor. The ½" large format sensor with a resolution of 2048 x 1536 pixels renders extremely low noise performance with extraordinary color accuracy. Higher frame rates can be achieved for preview or auto features using binning, subsampling, or AOI modes.

The PoE version also provides two additional general purpose I/Os (GPIOs). The power supply is provided by the screw-on, dust proof and splash water proof M12 circular connector.

Data

The UI-5480RE PoE is fitted with the 4.92 megapixel CMOS sensor (MT9P031STM). About half an inch in size, the sensor delivers a resolution of 2560 x 1920 pixels as well as rolling and global start shutter features. The sensor is extraordinarily sensitive and is a real megapixel CCD replacement. The various shutter modes provide ideal parameters for every application to produce sharp, low-noise images.

The PoE version also provides two additional general purpose I/Os (GPIOs). The power supply is provided by the screw-on, dust proof and splash water proof M12 circular connector.

Data

The UI-5490RE PoE with the 10 megapixel CMOS sensor (MT9J003STM/STC) from ON Semiconductor delivers every detail in top image quality at a resolution of 3840 x 2748 pixels. The integrated scaler allows you to select any image size you require. The sensor also provides horizontal and vertical binning for contrast enhancement as well as subsampling for fast preview modes. Full HDTV and quad HDTV resolutions are also possible.

The PoE version also provides two additional general purpose I/Os (GPIOs). The power supply is provided by the screw-on, dust proof and splash water proof M12 circular connector.

Data

The UI-5540RE PoE with the 1.3 megapixel CMOS sensor (MT9M001STM) from ON Semiconductor delivers the best price/performance ratio. Besides offering a megapixel resolution of 1280 x 1024 pixels, it also features horizontal and vertical subsampling modes for higher frame rates. The large pixels create an extremely good signal-to-noise ratio and therefore produce a high image dynamic.

The PoE version also provides two additional general purpose I/Os (GPIOs). The power supply is provided by the screw-on, dust proof and splash water proof M12 circular connector.

Data

The UI-5550RE PoE with the 1/3" 2 megapixel CMOS sensor (MT9D131STC) from ON Semiconductor delivers a resolution of 1600 x 1200 pixels at an aspect ratio of 4:3 and 18 frames per second. It can deliver low-noise preview images at a higher frame rate using subsampling.

The PoE version also provides two additional general purpose I/Os (GPIOs). The power supply is provided by the screw-on, dust proof and splash water proof M12 circular connector.

Data

The UI-5580RE PoE is fitted with the 4.92 megapixel CMOS sensor (MT9P006STC - color version) from ON Semiconductor. About half an inch in size, the sensor delivers a resolution of 2560 x 1920 pixels as well as rolling and global start shutter features. Thanks to the innovative A-Pix™ pixel technology, the sensor is extremely sensitive to light, which makes it an affordable alternative to many CCD sensors currently available on the market. This also makes the camera particularly suitable for applications that require maximum precision in color rendering and crystal clear image quality. The A-Pix™ pixel technology is based on the gathering of light by a lightguide, which directs the gathered incident light from the color filter to the surface of the photo diode. Structure and process improvements in pixel technology have increased the sensitivity of the sensor in the red and green range in particular by up to 30% compared to the previous version of the sensor.

Data

The UI-5120SE-M is a GigE camera with HDR (High Dynamic Range) CMOS sensor in CCIR/PAL resolution (768x576 pixels). Thanks to its logarithmic characteristic this sensor achieves a very high dynamic range of 120 dB, which is about 1,000 times more than conventional sensors can provide. Thus the UI-5120SE-M is perfectly suited for applications that have very high brightness differences.

Its extremely rugged housing meets the IP65 / IP67 protection classes when used together with an optional lens tube. The connectors for power and digital I/Os (opto-coupled, up to 30 V) as well as the GigE port are also splash water proof.

Data

The UI-5220SE is fitted with the ON Semiconductor monochrome or color WVGA sensor (MT9V032STM/MT9V032STC). The global shutter enables you to capture fast-moving objects. Thanks to the optional HDR (high dynamic range) mode, the CMOS sensor delivers excellent images even in high dynamic, high contrast scenes. The 1/3" sensor format makes the camera the ideal replacement for standard analog video cameras at no great expense.

Data

The UI-5240SE is a particularly powerful industrial camera with the e2v 1.3 megapixel CMOS sensor. This is one of the most sensitive sensors in the IDS product portfolio and it is available in monochrome, color (EV76C560ABT/EV76C560ACT), and NIR versions (EV76C661ABT). Besides its outstanding sensitivity to light in CCD quality, the camera also has a range of other distinctive features: For example, the sensor provides two global shutter and two rolling shutter modes, which you can switch between while the camera is in operation. This makes the sensor extremely flexible if requirements or ambient conditions change. There are also up to four areas of interest (AOI). You can use these either to check several features simultaneously or to capture AOIs in a sequence of exposures using a wide range of different parameters.

Data

The UI-5250SE with the e2v CMOS sensor with 2 megapixel resolution is an especially high-performance and versatile industrial camera (EV76C570). It has one of the most sensitive sensors in the IDS product portfolio and it is available in monochrome and color versions. Besides its outstanding sensitivity to light in CCD quality, the camera also has a range of other distinctive features: The sensor allows you to switch between various shutter modes, which allow you to capture sharp images of moving objects or extremely low-noise, high-contrast images. There are also up to four areas of interest (AOI). You can use these either to check several features simultaneously or to capture AOIs in a sequence of exposures using a wide range of different parameters.

Data

The UI-5460SE is fitted with the extremely light-sensitive 3.1 megapixel CMOS sensor (MT9T031STC) from ON Semiconductor. The ½" large format sensor with a resolution of 2048 x 1536 pixels renders extremely low noise performance with extraordinary color accuracy. Higher frame rates can be achieved for preview or auto features using binning, subsampling, or AOI modes.

Data

The UI-5480SE is fitted with the 5 megapixel CMOS sensor (MT9P031STM/MT9P031STC). About half an inch in size, the sensor delivers a resolution of 2560 x 1920 pixels as well as rolling and global start shutter features. The sensor is extraordinarily sensitive and is a real megapixel CCD replacement. The various shutter modes provide ideal parameters for every application to produce sharp, low-noise images.

Data

The UI-5490SE with the 10 megapixel CMOS sensor (MT9J003STM/STC) from ON Semiconductor delivers every detail in top image quality at a resolution of 3840 x 2748 pixels. The integrated scaler allows you to select any image size you require. The sensor also provides horizontal and vertical binning for contrast enhancement as well as subsampling for fast preview modes. Full HDTV and quad HDTV resolutions are also possible.

Data

The UI-5540SE with the 1.3 megapixel CMOS sensor (MT9M001STM) from ON Semiconductor delivers the best price/performance ratio. Besides offering a megapixel resolution of 1280 x 1024 pixels, it also features horizontal and vertical subsampling modes for higher frame rates. The large pixels create an extremely good signal-to-noise ratio and therefore produce a high image dynamic.

Data

The UI-5550SE with the 1/3" 2 megapixel CMOS sensor (MT9D131STC) from ON Semiconductor delivers a resolution of 1600 x 1200 pixels at an aspect ratio of 4:3 and 18 frames per second. It can deliver low-noise preview images at a higher frame rate using subsampling.

Data

The UI-5580SE is fitted with the 5 megapixel CMOS sensor (MT9P006STC - color version) from ON Semiconductor. About half an inch in size, the sensor delivers a resolution of 2560 x 1920 pixels as well as rolling and global start shutter features. Thanks to the innovative A-Pix pixel technology, the sensor is extremely sensitive to light, which makes it an affordable alternative to many CCD sensors currently available on the market. This also makes the camera particularly suitable for applications that require maximum precision in color rendering and crystal clear image quality. The A-Pix pixel technology from ON Semiconductor is based on the gathering of light by a lightguide, which directs the gathered incident light from the color filter to the surface of the photo diode. Structure and process improvements in pixel technology have increased the sensitivity of the sensor in the red and green range in particular by up to 30% compared to the previous version of the sensor.

Data

The UI-5640SE with the 1/3" 1.3 megapixel CMOS sensor (MT9M131STC) from ON Semiconductor delivers a resolution of 1280 x 1024 pixels at 25 frames per second. A higher frame rate can be achieved using the subsampling mode. The large pixels create a particularly noise-free image.

Data

The UI-5220CP is fitted with the ON Semiconductor monochrome or color WVGA sensor (MT9V032STM/MT9V032STC). The global shutter enables you to capture fast-moving objects. Thanks to the optional HDR (high dynamic range) mode, the CMOS sensor delivers excellent images even in high dynamic, high contrast scenes. The 1/3" sensor format makes the camera the ideal replacement for standard analog video cameras at no great expense.

Data

The UI-5240CP is a particularly powerful industrial camera with the e2v 1.3 megapixel CMOS sensor. This is one of the most sensitive sensors in the IDS product portfolio and it is available in monochrome, color (EV76C560ABT/EV76C560ACT), and NIR versions (EV76C661ABT). Besides its outstanding sensitivity to light in CCD quality, the camera also has a range of other distinctive features: For example, the sensor provides two global shutter and two rolling shutter modes, which you can switch between while the camera is in operation. This makes the sensor extremely flexible if requirements or ambient conditions change. There are also up to four areas of interest (AOI). You can use these either to check several features simultaneously or to capture AOIs in a sequence of exposures using a wide range of different parameters.

Data

The UI-5250CP with the e2v CMOS sensor with 2 megapixel resolution is an especially high-performance and versatile industrial camera (EV76C570). It has one of the most sensitive sensors in the IDS product portfolio and it is available in monochrome and color versions. Besides its outstanding sensitivity to light in CCD quality, the camera also has a range of other distinctive features: The sensor allows you to switch between various shutter modes, which allow you to capture sharp images of moving objects or extremely low-noise, high-contrast images. There are also up to four areas of interest (AOI). You can use these either to check several features simultaneously or to capture AOIs in a sequence of exposures using a wide range of different parameters.

Data

The GigE camera UI-5260CP is equipped with budget-priced 2.3 MP CMOS sensor Sony IMX249 that sets new standards in terms of light sensitivity, dynamic range and color reproduction. The GigE industrial camera provides excellent image quality with extraordinarily low-noise performance - at frame rates up to 41 fps (full resolution: 1900 x 1200 px). The sensor is perfect for applications demanding excellent image quality even in low-light conditions e.g. in ITS and in quality assurance. Also available as USB 3.0 version.

Data

The UI-5360CP is fitted with the highly-sensitive and fast 2.22 megapixel CMOS sensor from CMOSIS (CMV2000). The sensor provides a host of innovative and useful sensor features, including multiple AOI mode with up to 8 AOIs for the simultaneous checking of various characteristics, as well as a resolution of 2048 x 1088 pixels. Thanks to the innovative pixel architecture, fixed pattern noise and hiss are considerably reduced. The pipelining feature also allows further exposure while the sensor data is being read out, which effectively reduces motion blur and speeds up the readout.

Data

The UI-5370CP is fitted with the highly-sensitive and fast 4.19 megapixel CMOS sensor from CMOSIS (CMV4000). The sensor provides a host of innovative and useful sensor features as well as a resolution of 2048 x 2048 pixels. Thanks to the innovative pixel architecture, fixed pattern noise and hiss are considerably reduced. The pipelining feature also allows further exposure while the sensor data is being read out, which speeds up the readout and effectively reduces motion blur. With an extremely large optical format of 1", the sensor delivers large pixels and is extremely low-noise and sensitive to light.

Data

The UI-5480CP is fitted with the 5 megapixel CMOS sensor (MT9P031STM/MT9P031STC). About half an inch in size, the sensor delivers a resolution of 2560 x 1920 pixels as well as rolling and global start shutter features. The sensor is extraordinarily sensitive and is a real megapixel CCD replacement. The various shutter modes provide ideal parameters for every application to produce sharp, low-noise images.

Data

The UI-5580CP is fitted with the 5 megapixel CMOS sensor (MT9P006STC - color version) from ON Semiconductor. About half an inch in size, the sensor delivers a resolution of 2560 x 1920 pixels as well as rolling and global start shutter features. Thanks to the innovative A-Pix pixel technology, the sensor is extremely sensitive to light, which makes it an affordable alternative to many CCD sensors currently available on the market. This also makes the camera particularly suitable for applications that require maximum precision in color rendering and crystal clear image quality. The A-Pix pixel technology from ON Semiconductor is based on the gathering of light by a lightguide, which directs the gathered incident light from the color filter to the surface of the photo diode. Structure and process improvements in pixel technology have increased the sensitivity of the sensor in the red and green range in particular by up to 30% compared to the previous version of the sensor.

Data
